Moza AB6 Flight Simulator Bundle
Moza AB6 Flight Simulator Bundle
The MOZA AB6 Bundle pairs a high-torque 6 Nm force feedback base with the precision MHG flightstick, offering accurate force feedback, 29 programmable signals, and immersive flight control. Its compact, spacecraft-inspired design supports desktop clamp (included), optional baseplate, or direct hard-mount, adapting to any cockpit or desktop setup. Compatible with MOZA and select third-party flightsticks, as well as major flight simulators.
What's Included?
- MOZA AB6 Force Feedback Base
- MOZA MHG Flightstick
- Table Clamp for AB6 Base
- Power Adapter
- Power Cord
- Data Cable
- Toolkit
- User Manual
- Moza Sticker Kit
Table Clamp Included:
The Moza AB6 Flight Base comes with its own integrated desk clamp, designed for secure desktop mounting (up to 70mm thick) for immersive flight simulation, providing a wobble-free base for the 6Nm force feedback system, but users can also use the universal MOZA Racing or Flight Base clamps for broader compatibility with different setups, including aluminum profiles, ensuring rigidity and versatility.
6 Nm Force Feedback Base
The MOZA AB6 features a durable metal construction and delivers 6 N·m of consistent and precise force feedback.
MOZA Cockpit software allows users to fine-tune parameters such as centering force, damping, and friction, accurately simulating in-flight vibrations and aerodynamic responses for a truly immersive flight experience.
Full Metal Construction
Crafted from aluminum alloy and high-strength steel, the AB6 force feedback base offers a premium tactile feel, outstanding structural rigidity, and long-lasting durability.
Programmable Front Panel with RGB Lighting
The front panel includes 8 physical buttons for quick access to in-sim commands. Each button features fully customizable RGB backlighting with 16.7 million color options.
Dual Throttle Sliders
The base features two analog sliders that support various functions, including throttle and airbrake control, as well as camera and view adjustments.
High-Performance Outrunner Motor
Equipped with a high-torque outrunner motor, the AB6 FFB base delivers smooth, responsive control with excellent stability, ideal for precise aircraft handling in demanding flight scenarios.
15-bit Magnetic Encoder
High-resolution magnetic encoder ensures ultra-precise, low-latency input tracking.
Compact, Mount-friendly Design
The AB6's compact design allows for versatile installation, including center-mounting on flight rigs and other space-constrained setups.
*The desktop clamp is included in the kit.
AB6 Specs
| Dimensions |
188*123*163 mm |
| Housing Material |
Aluminum alloy |
| Dust Bag Material |
Microfiber leather |
| Weight |
2.95KG |
| Motors |
Dual high-performance servo motors |
| Roll Axis Continuous Torque |
4.4N·m |
| Peak Combined Torque |
6N·m |
| Travel Range |
±20° roll (X-axis), ±17° pitch (Y-axis) |
| Compatible Sticks |
All MOZA flight sticks |
| Power |
72W |
| Voltage Input |
110~220V AC —>12V DC |
| Game Resolution |
0-65535 |
| USB Polling Rate |
1000Hz |
| Mounting Options |
Desktop clamp (included), baseplate (sold separately), direct hard mount |
| Emergency Stop Switch |
Optional |
| Smart Telemetry-Based Force Feedback |
Supported (no plugin required) |
| Native Force Feedback Support |
√ |
| Platform |
PC |
| Included Accessories |
Power supply, power cable, data cable, toolkit, user manual, stickers |
MHG Specs
| Dimensions |
142.5*202*313mm |
| Casing Material |
Carbon fiber reinforced composite |
| Connector Material |
Metal |
| Button Cap Material |
ABS plastic |
| Weight |
395g |
| 5-Way Switches |
4 |
| Hall Effect Mini-Stick |
1 |
| Trigger Stages |
2 |
| Assignable Outputs |
25 |
| Included Accessories |
User manual, toolkit |
